Product Description
Pindee Threaded Gate valves are mainly used in municipal building construction, the main materials are cast steel, stainless steel gate valves.
Pindee Threaded Gate valve sold annually in large quantities to Southeast Asia, Africa, and North America. High quality and high quality service have been recognized by customers. We have a professional sales team to provide you with professional Threaded Gate Valve product knowledge.
Technical parameters:
| Main outer size | ||||||
| DN | G | L | E | B | H | W |
| 15 | 1/2” | 55 | 16 | 31 | 90 | 70 |
| 20 | 3/4” | 60 | 18 | 38 | 98 | 70 |
| 25 | 1” | 68 | 20 | 46 | 108 | 70 |
| 32 | 1-1/4” | 76 | 21.5 | 56 | 128 | 80 |
| 40 | 1-1/2” | 80 | 23 | 63 | 152 | 100 |
| 50 | 2” | 93 | 24.5 | 76 | 166 | 100 |
| Materials of main parts | ||||||
| Material | Z15H-(16-64)C | Z15H-(16-64)P | Z15H-(16-64)R | |||
| Body | WCB | ZG1Cr18Ni9TiCF8 | ZG1Cr18Ni12Mo2TiCF8M | |||
| Disc | WCB | ZG1Cr18Ni9TiCF8 | ZG1Cr18Ni12Mo2TiCF8M | |||
| Stem | 1Cr18Ni9Ti304 | 1Cr18Ni9Ti304 | 1Cr18Ni12Mo2Ti316 | |||
| Sealing | 304, 316 | |||||
| Packing | Polytetrafluorethylene(PTFE) | |||||
Pindee Valve Packing
